P/N
PS-TPT-0850FNFAG*-3
watts
850W
WATTS
TPD-850AH2FXG-3
Max. Output Capacity
850W
Color
Black
Dimension ( W / H / D )
150mm(W)x86mm(H)x140mm(D)
PFC (Power Factor Correction)
Active PFC
Power Good Signal
100-250 msec
Hold Up Time
17msec at 80% load
Input Current
10A Max.
Input Frequency Range
50Hz-60Hz
Input Voltage
100-240V~
OPERATING TEMPERATURE
0°C to + 40°C
Operating Humidity
5% to 85%,non-condensing
Storage Temperature
-40°C to + 70°C
Storage Humidity
5% to 95%, non-condensing
COOLING SYSTEM
12cm Hydraulic bearing fan
Efficiency
Meet 80 PLUS® Gold at 115Vac input.
MTBF
100,000 hrs minimum
Safety Approval
CE/UKCA/ICES/TUV/LVD/RCM/CB/FCC/cTUVus/BSMI/CCC/BIS/S-MARK
PCI-E 6+2pin
4
PCIe 12+4pin
1
PROTECTION
OVP/UVP/OCP/OPP/OTP/SCP
